Abbey Machinery
TRI AXLE SLURRY TANKERS
TRACTORS FORM 180 HP UPWARDS
The tri range is available in capacities from 16,000 to 22,000 litres, on either spring sets or bogeys that include steering, with various tyre options. All Abbey tankers can be optioned with a self-fill system, which can be operated from the tractor.

Overview

  1. Full length chassis with 4 point welding
  2. Tri axle
  3. Self-steering front & rear axle
  4. 550/60 x 22.5 flotation tyres
  5. Parabolic leaf spring drawbar (weight sensing)
  6. 10 mm box section drawbar
  7. Replaceable, greasable wear bushes on drawbar pivots
  8. 6 mm EN 42 high carbon steel
  9. Inverted splash plate for low and even spread
  10. Double trap system to prevent overfilling
  11. Pressed dome ends for extra strength
  12. Internally welded tanks
  13. Front sight tube and rear sight glass
  14. Hydraulic brakes
  15. Rear brackets to retro fit applicator
Tri Axle Slurry Tankers for Sale NZ
Tri Axle Slurry Tankers for Sale NZ
Warranty_1Year_Black-Lrg_RGB
Tri Axle Slurry Tankers for Sale NZ
Tri Axle Slurry Tankers for Sale NZ
Warranty_1Year_Black-Lrg_RGB

Features

Superior service, limited downtime

Farm with confidence when you choose Farmgard. Our comprehensive  after-sales service will keep you moving forward.

Models

MODELS CAPACITY (LITRES) MIN. TRACTOR REQUIRED (HP) FACT SHEET
3500 Tri 16,000 180 Download
4000 Tri 18,000 200 Download
4500 Tri 20,000 250 Download
5000 Tri 22,000 250 Download

Options

Galvanizing 6 or 8" autofill
6 or 8" turbofill Water cooled pump
hydraulic drive pump 560/600/650/710 flotation tyres
